Functions |
|
| |
To test the injector dribbling, blocking, atomization, the injector angle as well as the amount and uniformity at the different running speed.
To test conduct the physical and chemical cleaning of the blocked or trouble
injector, ultrasonic cleaning, test cleaning and on-vehicle cleaning.
With exclusive automatic device, it may regulate the current and voltaic injectors.
If use new type injector, just need choose the matched connector and
replace
the O-ring
Connectors are suit for all kinds of fuel injector,Including standard Hose/Tail
type, K type, TBI type.
May diagnose the injectors,Quality and injecting uniformity by best the
minimum open/colse cycle.
With automatic testing liquid recycle system.
Can clean the engine without dismantling (choose matched connector).
|
|
| |
| Technical parameters |
| Power: |
85-132vac/170-264vac 47-63Hz |
| Ultrasonic wave frequency: |
38-39KHz |
| Ultrasonic wave power: |
100W |
| Rotate speed: |
0-9975r/min, step: 25r/min |
| Pulse width: |
0-30ms, step: 0.1ms |
| Count: |
0-9975r, step: 25r |
| Time: |
0-9975S, step: 5S |
| System pressure: |
0-6.2kg/c©O (variable regulated) |
| System flow: |
4L/min |
| Test cylinder: |
6 (max) |
| Working temperature: |
-10¡ãC-60¡ãC |
|
|
| |
The small part of: |
|
| |
|
|
| |
|
|
| |
|
|
|
|
