Functions |
|
|
It can check the defects of leaking, blocking, atomization, the angle state of
the injector, also the a mount and the uniformity of spraying
oil when the Injectors are at different running speed.
It can simulate the accelerating or decelerating state of engine
ptionally.
With exclusive automatic device, it may regulate the current and
voltaic
injectors.
Equipped with high-low liquid level indicator.
Various conneetors are suit for different types of injectors, including
standard Hose/Hose/Tail type, K type, TBI type and the customized type.
May diagnose the injectors. Quality and injecting uniformity by best the
minimum open/colse cycle.
The back light makes the working state of injectors being shown
clearly.
Automatic testing liquid recycle system. |
|
|
Technical parameters |
Dimensions: |
400mmx510mmx450mm |
Weight: |
25kg |
Power: |
85-132vac/170-264vac 47-63Hz |
Fuel tank capacity: |
2.5L |
Test tube capacity: |
120CC |
Ultrasonic wave frequency: |
38-39KHz |
Ultrasonic wave power: |
100W |
Rotate speed: |
0-9975r/min, step: 25r/min |
Pulse width: |
0-30ms, step: 0.1ms |
Count: |
0-9975r, step: 25r |
Time: |
0-9975S, step: 5S |
System pressure: |
0-6.2kg/cİO (variable regulated£İ |
System flow: |
4L/min |
Test cylinder: |
6 (max) |
|
|
|
The small part of: |
|
|
|
|
|
|
|
|
|
|
|
|
